Vertical Semi-Automatic Winding Machine For SWG

The Kaxite Vertical Semi-Automatic Winding Machine for SWG expertly coils wires with precision, enhancing efficiency in industrial settings. Its durable design and user-friendly interface reduce downtime, while advanced technology ensures consistent, high-quality results. Ideal for manufacturers and workshops, it solves winding challenges and boosts productivity, offering a reliable, superior alternative to traditional models. Experience seamless operation and elevate your production with Kaxite.

Send Inquiry

Product Description

Vertical semi-automatic winding machine for SWG Details

STYLE	KXT E500B Vertical semi-automatic winding machine for SWG
Producing ability	Can produce 2"-18" SWG with or without inner ring; Standard package including models for 2"-10" 150# SWG with or without inner ring, other size model on request with extra charge
SWG thickness	4.5mm (also suitable for 3.2 and 6.4mm after changing roller parts, V shape winding or W shape winding)
Maximum gasket OD	500mm
Minimum gasket ID	50mm
Gasket OD tolerance	±0.2mm
Spindle speed	0--200rpm
Total power	8kw
Spindle motor power	1.5kw
Welder power	6kw
Power supply voltage	380V/220V for option, 3 phases
Air compressor	0.6-0.8 MPA
Frequency Converter	2.2G
PLC	xinjie
Machine measurement	140010501650mm
Machine net weight	480kg
